<APPENDIX 1. LIST OF PARAMETERS FOR EACH BLOCK OF RAMC>
A-5
All Rights Reserved. Copyright © 2006, Rota Yokogawa
IM 01R01B02-01E-E 5th edition October 01, 2020 -00
Abs.
Index
Parameter Sub-
Parameter
Label Data Type/
Structure
Read/
Write
Initial value Functional Description
Value OUT Value Float R/W 0 Indication and input of value (setting
dependent)
Status OUT Status Unsigned8 R/W 0x80: GOOD Indication and input of status (setting
dependent)
27 PV_SCALE - Array of
Float
R/W - Conversion of the process variable into
percent using the high and low scale
values
Array1 PV Scale Upper
Value
Float R/W Det. by ordered
scale
Input and indication of the value corre-
sponding to 100 % of scale
Array2 PV Scale Lower
Value
Float R/W 0 Input and indication of the value corre-
sponding to 0 % of scale
28 OUT_SCALE - DS-36 R/W - Input and indication of process
variable's scale
EU_at_100% OUT Scale Upper
Value
Float R/W Det. by ordered
scale
Corresponding OUT scale value to
100 %
EU_at_0% OUT Scale Lower
Value
Float R/W 0 Corresponding OUT scale value to 0 %
Units_Index Unit Unsigned16 R/W Det. by ordered
scale
Indication and setting of the OUT scale
unit
Decimal_Point Decimal Point Integer8 R/W 2 Memo of the number of valid digits
below decimal point
29 LIN_TYPE Characterization
Type
Unsigned8 R/W 0: No Linearisation Input and indication of linearization type
30 CHANNEL Channel Unsigned16 R/W Det. by ordered
scale
Reference to the active Transducer
Block which provides the measurement
value
32 PV_FTIME Filter Time Constant Float R/W 0.0 Time constant of a single exponential
lter for the PV, in seconds
33 FSAFE_TYPE Fail Safe Mode Unsigned8 R/W 1 In case of BAD status the OUT is adju-
sted based on the following settings:
0: Value: FSAFE_VALUE, Status:
UNCERTAIN - Substitute Value
1: Value: last stored valid value, Status:
UNCERTAIN-last usable value
2: Value: actual, Status: no adjustment
34 FSAFE_VALUE Fail Safe Default
Value
Float R/W 0 Default value for the OUT parameter in
case of BAD status.
35 ALARM_HYS Limit Hysteresis Float R/W 0.5 Absolute value of OUT value must re-
turn within the alarm limits before alarm
condition clears (in OUT scale unit).
37 HI_HI_LIM Upper Limit Alarm Float R/W 3.40282346E+38:
INF
Setting of the upper limit alarm value (in
OUT scale unit)
39 HI_LIM Upper Limit
Warning
Float R/W 3.40282346E+38:
INF
Setting of the upper limit warning value
(in OUT scale unit)
41 LO_LIM Lower Limit
Warning
Float R/W -3.40282346E+38:
-INF
Setting of the lower limit warning value
(in OUT scale unit)
43 LO_LO_LIM Lower Limit Alarm Float R/W -3.40282346E+38:
-INF
Setting of the lower limit alarm value (in
OUT scale unit)
46 HI_HI_ALM - DS-39 R/- - State of the upper alarm limit
Unacknowledged Upper Unack.
Alarms
Unsigned8 R/- 0 For future use (not available)
Alarm_State Upper Alarm
Status
Unsigned8 R/- 0: No Alarm Indicates the alarm status
Time Stamp - Time Value R/- 0 For future use (not available)
Subcode - Unsigned16 R/- 0 For future use (not available)
Value Upper Alarm
Output Value
Float R/- 0 Indicates the value which caused the
alarm
47 HI_ALM - DS-39 R/- - State of the upper warning limit
Unacknowledged Upper Unack.
Warnings
Unsigned8 R/- 0 For future use (not available)
Alarm_State Upper Warning
Status
Unsigned8 R/- 0: No Warning Indicates the warning status
Time Stamp - Time Value R/- 0 For future use (not available)
Subcode - Unsigned16 R/- 0 For future use (not available)
Value Upper Warning
Output Value
Float R/- 0 Indicates the value which caused the
warning
* Writable in block mode "MAN" only!
