50 (1.97)
FS40-S22-TP
Ø 54
(2.12)
1 1/4" NPT
41 (1.61)
FS40-V22-TP
FS40-F22-TP
61 (2.40)
Ø 55
(2.16)
1 1/4"-11.5
NPT
36 (1.42)
27 (1.06)
24 (0.95)
Ø 63
(2.48)
FS40-S23-DF
Ø 28
(1.10)
Ø 31
(1.22)
FS40-S22-WE
Ø 54
(2.12)
Ø 38
(1.50)
36 (1.42)
Ø 36
(1.42)
27 (1.06)
52 (2.05)
Ø 55
(2.16)
1 1/4" ISO
228/1-G 1
1/4
27 (1.06)
19 (0.75)
FS40-F22-PA
57 (2.25)
Ø 50
(1.97)
32 (1.26)
24 (0.95)
Ø 40
(1.57)
FS40-V22-WE
Fig. 19 Dimensions FS40 Flow fitting subassemblies
