036-21233-002-A-0903
Unitary Products Group 13
TABLE 8: DNH048 COOLING CAPACITIES - 4 TON
TEMPERATURE
OF AIR ON
CONDENSER COIL
AIR ON EVAPORATOR COIL
1,200 CFM 1,400 CFM 1,600 CFM 1,800 CFM 2,000 CFM
WB °FWB °FWB °FWB °FWB °F
72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57
85 °F
NET CAP.
MBH
50.8 47.4 43.1 42.8 52.8 49.3 44.8 44.5 54.8 51.2 46.5 46.2 55.5 51.9 47.1 46.8 56.2 52.5 47.7 47.4
TOTAL POWER
INPUT kW
4.01 3.98 4.02 3.98 4.06 4.03 4.07 4.03 4.11 4.08 4.12 4.08 4.24 4.20 4.25 4.20 4.36 4.33 4.37 4.33
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 30.9 38.8 43.1 42.8 34.6 43.3 44.8 44.5 38.2 47.7 46.5 46.2 41.0 50.1 47.1 46.8 43.8 52.5 47.7 47.4
83 27.5 35.4 41.8 41.8 30.5 39.2 44.2 44.0 33.6 43.0
46.5 46.2 35.7 45.6 47.1 46.8 37.8 48.3 47.7 47.4
80 24.1 32.0 38.4 38.4 26.5 35.2 42.3 42.2 28.9 38.4 46.1 46.1 30.4 40.3 46.9 46.7 31.8 42.3
47.7 47.4
77 20.7 28.6 35.0 35.0 22.4 31.1 38.2 38.2 24.2 33.7 41.4 41.4 25.1 35.0 41.6 41.4 25.9 36.3 41.7 41.4
74 17.2 25.1 31.6 31.6 18.4 27.1 34.2 34.2 19.6 29.0 36.8 36.8 19.7 29.7 36.3 36.1 19.9 30.4 35.8 35.5
71 - 21.7 28.1 28.1 - 23.0 30.1 30.1 - 24.4 32.1 32.1 - 24.4 31.0 30.8 - 24.4 29.8 29.5
68 - 18.3 24.7 24.7 - 19.0 26.1 26.1 - 19.7 27.4 27.4 - 19.1 25.6 25.5 - 18.4 23.9 23.6
95 °F
NET CAP.
MBH
48.7 44.9 40.8 40.7 50.8 46.8 42.6 42.4 52.9 48.8 44.4 44.2 54.8 50.5 46.0 45.8 56.7 52.3 47.5 47.4
TOTAL POWER
INPUT kW
4.34 4.34 4.38 4.35 4.39 4.39 4.43 4.40 4.44 4.43 4.47 4.44 4.56 4.56 4.60 4.57 4.68 4.68 4.72 4.69
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 29.7 36.7 40.8 40.7 33.7 41.6 42.6 42.4 37.8 46.5 44.4 44.2 41.5 49.4 46.0 45.8 45.2 52.3 47.5 47.4
83 26.2 33.3 38.8 38.9 29.7 37.6 41.6 41.6 33.1 41.9
44.4 44.2 36.2 45.7 46.0 45.8 39.2 49.5 47.5 47.4
80 22.8 29.8 35.3 35.5 25.6 33.5 39.7 39.9 28.4 37.2 44.0
44.2 30.8 40.4 45.8 45.8 33.3 43.5 47.5 47.4
77 19.4 26.4 31.9 32.1 21.6 29.5 35.6 35.8 23.8 32.5 39.4 39.6 25.5 35.1 40.5 40.5 27.3 37.6 41.6 41.4
74 13.0 23.0 28.5 28.6 17.5 25.6 31.6 31.8 19.1 27.9 34.7 34.9 20.2 29.7 35.2 35.2 21.4 31.6 35.6 35.4
71 - 19.6 25.1 25.2 - 21.4 27.6 27.7 - 23.2 30.0 30.2 - 24.4 29.8 29.8 - 25.7 29.6 29.5
68 - 16.2 21.6 21.8 - 17.3 23.5 23.7 - 18.5 25.4 25.6 - 19.1 24.5 24.5 - 19.7 23.7 23.5
105 °F
NET CAP.
MBH
47.9 43.1 39.9 39.9 48.9 44.0 40.8 40.7 49.9 44.9 41.6 41.5 51.4 46.3 42.8 42.8 52.8 47.6 44.1 44.0
TOTAL POWER
INPUT kW
4.78 4.78 4.81 4.78 4.83 4.83 4.86 4.83 4.88 4.88 4.91 4.88 5.01 5.01 5.04 5.01 5.14 5.14 5.17 5.14
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 31.8 39.0 39.9 39.9 34.3 41.4 40.8 40.7 36.9 43.8 41.6 41.5 40.3 45.7 42.8 42.8 43.8 47.6 44.1 44.0
83 28.4 35.7 38.9 39.0 30.3 38.0 40.2 40.3 32.2 40.3
41.6 41.5 35.0 43.3 42.8 42.8 37.9 46.2 44.1 44.0
80 24.9 32.3 37.2 37.3 26.2 34.0 39.2 39.4 27.5 35.7 41.2
41.5 29.7 38.5 42.6 42.7 31.9 41.4 44.1 44.0
77 21.5 28.9 33.8 33.9 22.2 29.9 35.1 35.3 22.9 31.0 36.5 36.8 24.4 33.2 37.3 37.4 26.0 35.4 38.1 38.0
74 18.1 25.4 30.3 30.4 18.1 25.9 31.1 31.3 18.2 26.3 31.9 32.1 19.1 27.9 32.0 32.1 20.0 29.4 32.1 32.1
71 - 22.0 26.9 27.0 - 21.8 27.1 27.3 - 21.7 27.2 27.5 - 22.6 26.7 26.8 - 23.5 26.2 26.1
68 - 18.6 23.5 23.6 - 17.8 23.0 23.2 - 17.0 22.5 22.8 - 17.3 21.4 21.5 - 17.5 20.2 20.2
115 °F
NET CAP.
MBH
47.1 41.3 39.0 39.1 47.0 41.2 38.9 39.0 46.8 41.0 38.8 38.8 47.9 42.0 39.7 39.7 49.0 43.0 40.6 40.6
TOTAL POWER
INPUT kW
5.22 5.22 5.24 5.21 5.27 5.27 5.29 5.26 5.32 5.32 5.34 5.31 5.45 5.46 5.48 5.45 5.59 5.59 5.61 5.58
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 33.9 41.3 39.0 39.1 34.9 41.2 38.9 39.0 36.0 41.0 38.8 38.8 39.2 42.0 39.7 39.7 42.5 43.0 40.6 40.6
83 30.5 38.1
39.0 39.1 30.9 38.5 38.9 39.0 31.3 38.8 38.8 38.8 33.9 40.9 39.7 39.7 36.5 43.0 40.6 40.6
80 27.1 34.7
39.0 39.1 26.9 34.4 38.7 38.9 26.6 34.1 38.4 38.7 28.6 36.7 39.5 39.7 30.6 39.2 40.6 40.6
77 23.7 31.3 35.6 35.7 22.8 30.4 34.7 34.9 22.0 29.5 33.7 34.1 23.3 31.4 34.2 34.4 24.6 33.2 34.6 34.7
74 20.2 27.9 32.2 32.3 18.8 26.3 30.6 30.8 17.3 24.8 29.0 29.4 18.0 26.0 28.9 29.1 18.6 27.3 28.7 28.7
71 - 24.5 28.8 28.8 - 22.3 26.6 26.8 - 20.1 24.4 24.7 - 20.7 23.5 23.7 - 21.3 22.7 22.8
68 - 21.0 25.3 25.4 - 18.3 22.5 22.7 - 15.5 19.7 20.1 - 15.4 18.2 18.4 - 15.3 16.7 16.8
125 °F
NET CAP.
MBH
46.4 39.6 38.2 38.3 45.1 38.4 37.1 37.2 43.7 37.1 36.0 36.1 44.5 37.7 36.5 36.7 45.2 38.3 37.1 37.3
TOTAL POWER
INPUT kW
5.70 5.70 5.70 5.60 5.70 5.70 5.70 5.70 5.80 5.80 5.80 5.70 5.90 5.90 5.90 5.90 6.00 6.10 6.10 6.00
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 36.1 43.7 38.2 38.3 35.6 41.0 37.1 37.2 35.1 38.3 36.0 36.1 38.1 38.3 36.5 36.7 41.1 38.3 37.1 37.3
83 32.6 40.6 39.2 39.2 31.5 38.9 37.6 37.7 30.4 37.3
36.0 36.1 32.8 38.5 36.5 36.7 35.2 39.7 37.1 37.3
80 29.2 37.2 40.9 40.9 27.5 34.9 38.2 38.4 25.7 32.6 35.5 36.0 27.5 34.8 36.3 36.6 29.2 37.0
37.1 37.3
77 25.8 33.7 37.5 37.5 23.4 30.8 34.2 34.4 21.1 26.0 30.9 31.3 22.2 29.0 31.0 31.3 23.3 31.1 31.2 31.3
74 22.4 30.3 34.0 34.1 19.4 26.8 30.1 30.4 16.4 23.3 26.2 26.7 16.8 24.2 25.7 26.0 17.3 25.1 25.2 25.4
71 - 26.9 30.6 30.6 - 22.8 26.1 26.3 - 18.6 21.5 22.0 - 18.9 20.4 20.7 - 19.1 19.2 19.4
68 - 23.5 27.2 27.2 - 18.7 22.0 22.3 - 14.0 16.9 17.3 - 13.6 15.1 15.4 - 13.2 13.3 13.4
1.
These capacities are net capacities (the indoor fan heat is deducted).
ALL SENSIBLE CAPACITY
