York DNH018 - Physical Data

036-21233-002-A-0903
6 Unitary Products Group
TABLE 1: PHYSICAL DATA
MODEL
DNH
018 024 030 036 042 048 060
EVAPORATOR
BLOWER
CENTRIFUGAL BLOWER (Dia. x W. in.) 10 X 8 10 X 8 10 X 8 11 x 10 11 x 10 12 x 11 12 x 11
FAN MOTOR HP (3 Speed) 1/2 1/2 1/2 3/4 3/4 3/4 1
EVAPORATOR
COIL
ROWS DEEP 2233333
FINS PER INCH 13 15 13 13 13 16 16
FACE AREA (Sq. Ft.) 3.5 3.5 3.5 3.5 4.5 4.5 4.5
CONDENSER
FAN
PROPELLER DIA. (in.) 22222222222222
FAN MOTOR HP 1/4 1/4 1/4 1/4 1/4 1/3 1/3
NOM. CFM TOTAL 1,800 2,200 2,400 2,400 2,400 3,000 3,000
CONDENSER
COIL
ROWS DEEP 1112122
FINS PER INCH 20 20 20 20 20 20 20
FACE AREA (Sq. Ft.) 11.7 11.7 11.7 11.7 14.7 14.7 14.7
CHARGE REFRIGERANT 22 (lbs./oz.) 4 / 6 4 / 6 4 / 9 6 / 12 5 / 14 8 / 0 7 / 14
FILTER FACE AREA (Sq. Ft.) Size (Nominal) 2.6/20x20 2.6/20x20 2.6/20x20 2.6/20x20
3.3/20x12
(2 Reqd.)
3.3/20x12
(2 Reqd.)
3.3/20x12
(2 Reqd.)
FURNACE
SECTION
NATURAL GAS BURNER ORIFICE NO.
(Drill Size)
43 43 43 43 40 40 40
PROPANE BURNER ORIFICE NO.
(Drill Size)
55 55 55 55 53 53 53
GAS CONNECTION SIZE 1/2 NPTI 1/2 NPTI
1/2
NPTI 1/2 NPTI 1/2 NPTI 1/2 NPTI 1/2 NPTI
COMPRESSOR HERMETIC TYPE, (Qty. = 1)
Reciprocat-
ing
Reciprocat-
ing
Scroll Scroll Scroll Scroll Scroll
