TABLE 3: DNH018 COOLING CAPACITIES - 1-1/2 TON
TEMPERATURE
OF AIR ON
CONDENSER COIL
AIR ON EVAPORATOR COIL
450 CFM 525 CFM 600 CFM 675 CFM 750 CFM
WB °FWB °FWB °FWB °FWB °F
72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57
85 °F
NET CAP.
MBH
16.0 15.0 13.5 13.7 18.0 16.8 15.2 15.4 19.9 18.7 16.8 17.1 20.3 19.0 17.1 17.4 20.7 19.4 17.5 17.7
TOTAL POWER
INPUT kW
1.61 1.61 1.60 1.60 1.62 1.61 1.61 1.61 1.62 1.61 1.61 1.61 1.64 1.63 1.63 1.63 1.66 1.65 1.65 1.65
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 9.0 11.6 13.5 13.7 11.1 14.0 15.2 15.4 13.2 16.5 16.8 17.1 12.9 16.3 17.1 17.4 12.5 16.1 17.5 17.7
83 8.5 11.1 13.1 13.6 10.1 13.1 15.0 15.3 11.7 15.0
16.8 17.1 11.8 15.3 17.1 17.4 11.9 15.6 17.5 17.7
80 8.0 10.6 12.7 13.1 9.1 12.1 14.4 14.9 10.3 13.6 16.1 16.8 10.8 14.3 16.8 17.2 11.3 15.0
17.5 17.7
77 7.6 10.2 12.2 12.7 8.2 11.1 13.4 14.0 8.8 12.1 14.7 15.3 9.8 13.2 15.8 16.2 10.8 14.4 16.9 17.2
74 7.1 9.7 11.7 12.2 7.2 10.1 12.5 13.0 7.3 10.6 13.2 13.8 8.7 12.2 14.8 15.2 10.2 13.8 16.3 16.6
71 - 9.2 11.3 11.7 - 9.2 11.5 12.0 - 9.1 11.7 12.3 - 11.2 13.7 14.2 - 13.3 15.7 16.0
68 - 8.8 10.8 11.3 - 8.2 10.5 11.1 - 7.6 10.2 10.8 - 10.2 12.7 13.1 - 12.7 15.2 15.4
95°F
NET CAP.
MBH
15.2 13.6 12.2 12.4 17.1 15.2 13.8 13.9 18.9 16.9 15.3 15.5 9.5 17.5 15.8 16.0 20.2 18.0 16.3 16.5
TOTAL POWER
INPUT kW
1.75 1.72 1.73 1.72 1.75 1.72 1.73 1.72 1.75 1.72 1.73 1.72 1.77 1.74 1.75 1.74 1.79 1.76 1.78 1.76
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 10.4 12.7 12.2 12.4 11.8 14.5 13.8 13.9 13.3 16.2 15.3 15.5 12.9 16.1 15.8 16.0 12.5 15.9 16.3 16.5
83 9.0 11.3
12.2 12.4 10.4 13.0 13.8 13.9 11.7 14.6 15.3 15.5 11.8 15.0 15.8 16.0 11.9 15.3 16.3 16.5
80 7.7 10.0 11.5 11.6 8.9 11.5 13.2 13.3 10.1 13.0 15.0 15.1 10.7 13.9 15.6 15.8 11.3 14.7
16.3 16.5
77 6.4 8.6 10.2 10.2 7.4 10.0 11.8 11.8 8.4 11.4 13.4 13.5 9.6 12.8 14.5 14.7 10.8 14.1 15.7 15.9
74 5.0 7.3 8.8 8.9 5.9 8.6 10.3 10.4 6.8 9.8 11.8 11.9 8.5 11.7 13.5 13.6 10.2 13.6 15.1 15.3
71 - 6.0 7.5 7.5 - 7.1 8.8 8.9 - 8.2 10.2 10.3 - 10.6 12.4 12.5 - 13.0 14.5 14.7
68 - 4.6 6.1 6.2 - 5.6 7.3 7.4 - 8.6 8.6 8.7 - 9.5 11.3 11.4 - 12.4 14.0 14.2
105°F
NET CAP.
MBH
13.6 11.8 10.8 11.0 15.3 13.3 12.2 12.4 17.0 14.8 13.6 13.8 17.6 15.3 14.0 14.3 18.1 15.7 14.5 14.7
TOTAL POWER
INPUT kW
1.87 1.83 1.85 1.84 1.87 1.84 1.85 1.84 1.87 1.84 1.85 1.84 1.90 1.86 1.87 1.87 1.92 1.88 1.90 1.89
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 9.0 11.1 10.8 11.0 10.2 12.7 12.2 12.4 11.5 14.3 13.6 13.8 11.7 14.5 14.0 14.3 11.9 14.7 14.5 14.7
83 8.1 10.2
10.8 10.9 9.3 11.7 12.2 12.4 10.5 13.2 13.6 13.8 10.9 13.8 14.0 14.3 11.3 14.4 14.5 14.7
80 7.2 9.3 10.3 10.3 8.3 10.7 11.8 11.9 9.4 12.2 13.4 13.5 10.1 13.0
14.0 14.1 10.8 13.9 14.5 14.7
77 6.3 8.4 9.4 9.4 7.4 9.8 10.9 10.9 8.4 11.1 12.4 12.4 9.3 12.2 13.2 13.3 10.2 13.3 13.9 14.2
74 5.5 7.6 8.5 8.6 6.4 8.8 9.9 10.0 7.4 10.1 11.3 11.4 8.5 11.4 12.4 12.5 9.6 12.8 13.4 13.6
71 - 6.7 7.6 7.7 - 7.9 9.0 9.0 - 9.0 10.3 10.3 - 10.6 11.6 11.7 - 12.2 12.8 13.1
68 - 5.8 6.8 6.8 - 6.9 8.0 8.1 - 8.0 9.2 9.3 - 9.8 10.8 10.9 - 11.6 12.3 12.5
115°F
NET CAP.
MBH
12.0 10.0 9.4 9.6 13.5 11.3 10.7 10.9 15.1 12.6 11.9 12.2 15.6 13.0 12.3 12.6 16.1 13.5 12.7 13.0
TOTAL POWER
INPUT kW
1.99 1.95 1.96 1.96 1.99 1.95 1.96 1.96 2.00 1.96 1.97 1.96 2.02 1.98 1.99 1.99 2.05 2.00 2.02 2.01
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 7.5 9.4 9.4 9.6 8.7 10.9 10.7 10.9 9.8 12.3 11.9 12.2 10.5 12.9 12.3 12.6 11.3 13.5 12.7 13.0
83 7.1 9.0
9.4 9.4 8.2 10.4 10.7 10.8 9.3 11.8 11.9 12.2 10.0 12.6 12.3 12.6 10.7 13.5 12.7 13.0
80 6.7 8.6 9.0 9.0 7.8 10.0 10.4 10.5 8.8 11.3 11.8 11.9 9.5 12.2
12.3 12.4 10.2 13.1 12.7 13.0
77 6.3 8.2 8.6 8.6 7.3 9.5 10.0 10.0 8.4 10.8 11.4 11.4 9.0 11.7 11.8 11.9 9.6 12.5 12.2 12.5
74 5.9 7.8 8.2 8.2 6.9 9.1 9.5 9.6 7.9 10.4 10.9 10.9 8.5 11.2 11.3 11.4 9.1 12.0 11.6 11.9
71 - 7.4 7.8 7.8 - 8.6 9.1 9.1 - 9.9 10.4 10.4 - 10.7 10.7 10.9 - 11.4 11.1 11.4
68 - 7.0 7.4 7.4 - 8.2 8.7 8.7 - 9.4 9.9 10.0 - 10.1 10.2 10.4 - 10.9 10.6 10.8
125°F
NET CAP.
MBH
10.4 8.2 8.0 8.3 11.8 9.3 9.1 9.4 13.2 10.5 10.3 10.5 13.7 10.8 10.6 10.9 14.1 11.2 10.9 11.3
TOTAL POWER
INPUT kW
2.11 2.06 2.08 2.08 2.12 2.07 2.08 2.08 2.12 2.07 2.08 2.08 2.15 2.10 2.11 2.11 2.18 2.12 2.14 2.14
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 6.1 7.8 8.0 8.3 7.1 9.1 9.1 9.4 8.1 10.3 10.3 10.5 9.3 11.3 10.6 10.9 10.6 12.3 10.9 11.3
83 6.2 7.9
8.0 8.0 7.2 9.1 9.1 9.3 8.1 10.4 10.3 10.5 9.1 11.5 10.6 10.9 10.1 12.5 10.9 11.3
80 6.2 7.9 7.8 7.8 7.2 9.2 9.0 9.0 8.2 10.5
10.3 10.3 8.9 11.3 10.6 10.8 9.6 12.2 10.9 11.3
77 6.3 8.0 7.8 7.9 7.3 9.3 9.1 9.1 8.3 10.6
10.3 10.4 8.7 11.1 10.4 10.6 9.1 11.7 10.4 10.7
74 6.4 8.1 7.9 7.9 7.4 9.4 9.2 9.2 8.4 10.6 10.4 10.4 8.5 10.9 10.2 10.3 8.5 11.2 9.9 10.2
71 - 8.1 8.0 8.0 - 9.4 9.2 9.3 - 10.7 10.5 10.5 - 10.7 9.9 10.1 - 10.7 9.4 9.7
68 - 8.2 8.0 8.1 - 9.5 9.3 9.3 - 10.8 10.6 10.6 - 10.5 9.7 9.9 - 10.1 8.9 9.2
1.
These capacities are net capacities (the indoor fan heat is deducted).
ALL SENSIBLE CAPACITY
