York DNH018 - Unit Dimensions - Back & Bottom; Unit Dimensions - Front & Bottom

036-21233-002-A-0903
22 Unitary Products Group
FIGURE 5 - UNIT DIMENSIONS - FRONT & BOTTOM
FIGURE 6 - UNIT DIMENSIONS - BACK & BOTTOM
26-3/4
6
4-5/8
8-7/8
11-7/8
19-1/4
HIGH VOLTAGE
C O N N . 1 -3 /3 2 " D IA .
KNO CKOUT
FRO N T
CONDENSATE
D R A IN 3 /4 "' N P T I
GAS SUPPLY 1-5/8" DIA.
KNO CKOUT (1/2" NPTI
CONNECTION)
LOW VO LTAG E CO NN.
1/8" D IA. KN O C KO U T
1-3/4
15
29-9/16
15
3-1/2
1-3/4
1-3/4
15
4
14-1/2
3-1/2
3-3/8
14-1/2
28-3/8
14-1/2
CONDENSER
COIL
BOTTOM SUPPLY
AIR O PENING
BOTTOM RETURN
AIR O PENING
SIDE RETURN
AIR O PENING
SIDE SUPPLY
AIR O PENING
BACK
