York DNH018 - Electrical Data

036-21233-002-A-0903
20 Unitary Products Group
TABLE 16: ELECTRICAL DATA
MODEL
DNH
POWER
SUPPLY
VOLTAGE
LIMITATIONS
1
COMPRESSOR
COND.
FAN
MOTOR,
FLA
SUPPLY
AIR
BLOWER
MOTOR
FLA
MINIMUM
CIRCUIT
AMPACITY
MAX.
FUSE
SIZE,
AMPS
2
MAX.
HACR
BREAKER
SIZE,
AMPS
UNIT
POWER
FACTOR
TRANSFORMER
SIZE (VA)
MIN. MAX. RLA LRA
018 208/230-1-60 187 253 7.1 48 1.1 2.6 12.5 15 15 .96 40
024 208/230-1-60 187 253 9.3 57 1.1 2.6 15.3 20 20 .96 40
030 208/230-1-60 187 253 13.6 67 1.1 2.6 20.7 30 30 .96 40
030 208/230-3-60 187 253 8.6 55 1.1 2.6 14.5 20 20 .96 75
030 460-3-60 414 504 4.3 27 0.6 1.4 7.4 15 15 .96 75
036 208/230-1-60 187 253 17.2 88 1.1 3.5 26.1 35 35 .96 40
036 208/230-3-60 187 253 11.4 77 1.1 3.5 18.9 25 25 .96 75
036 460-3-60 414 504 5.7 39 0.6 1.8 9.5 15 15 .96 75
036 575-3-60 518 630 4.7 31 0.4 1.5 7.8 15 15 .96 75
042 208/230-1-60 187 253 20.0 104 1.3 3.5 29.8 40 40 .96 40
042 208/230-3-60 187 253 13.9 88 1.3 3.5 22.2 30 30 .96 75
042 460-3-60 414 504 6.4 44 0.7 1.8 10.5 15 15 .96 75
042 575-3-60 518 630 5.4 34 0.5 1.5 8.8 15 15 .96 75
048 208/230-1-60 187 253 23.4 126 1.9 4.2 35.4 45 45 .96 40
048 208/230-3-60 187 253 13.0 93 1.9 4.2 22.4 30 30 .96 75
048 460-3-60 414 504 6.4 46.5 1.0 2.1 11.1 15 15 .96 75
048 575-3-60 518 630 5.1 37.2 0.8 1.7 8.9 15 15 .96 75
060 208/230-1-60 187 253 32.1 148 1.9 9.4 51.4 70 70 .96 40
060 208/230-3-60 187 253 19.3 123 1.9 9.4 35.4 45 45 .96 75
060 460-3-60 414 504 10.0 62 1.0 9.4 18.2 25 25 .96 75
060 575-3-60 518 630 7.9 50 0.8 2.8 13.5 20 20 .96 75
1.
Utilization range “A” in accordance with ARI Standard 110.
2.
Dual element, time delay type.
