TABLE 9: SUPPLY AIR BLOWER PERFORMANCE -DEE/DEG048 W/ BELT DRIVE & SIDE DUCT
1
2
MODEL
DEE/DEG
AIR
FLOW
CFM
AVAILABLE EXTERNAL STATIC PRESSURE - IWG
3
0.20 0.30 0.40 0.50 0.60 0.70 0.80
RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS
048
2000 843 860 880 925 919 1005 956 1065 993 1145 1030 1195 1067 1235
1900 817 775 854 850 893 920 930 995 970 1065 1008 1125 1046 1170
1800 790 700 828 760 867 840 906 905 944 980 985 1040 1025 1100
1700 - - 802 670 840 745 881 815 920 900 961 970 1001 1030
1600 - - - - 818 665 858 740 898 820 940 890 980 950
1500 - - - - - - 842 695 882 755 922 835 962 895
1400 - - - - - - 833 650 867 705 904 765 942 820
1300 - - - - - - - - 858 665 893 725 932 785
1200 - - - - - - - - 847 640 880 680 916 730
MODEL
DEE/DEG
AIR
FLOW
CFM
AVAILABLE EXTERNAL STATIC PRESSURE - IWG
3
0.90 1.00 1.10 1.20 1.30 1.40 1.50
RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS RPM WATTS
048
200011031270------------
190010851210------------
18001064114511021180----------
1700104010751081111511211140--------
1600102010051060105011001085--------
15001003945104499510861035--------
14009828801024920106796511071000------
1300970835101087010539201099960------
120095378099281510348551080905------
1.
230/460/575 Volts
2.
For 208 Volts multiply values by 0.95.
3.
Includes allowances for a wet evaporator coil, 1” filters, and the heat exchangers. Refer to Table 12 for resistance values on applications
other than gas / electric units with side duct airflows.
