TABLE 11: SUPPLY AIR BLOWER PERFORMANCE - DEE/DEG036-060 W/ DIRECT DRIVE
1
MODEL
DEE/DEG
MOTOR
SPEED
AVAILABLE EXTERNAL STATIC PRESSURE - IWG
2
0.20 0.30 0.40 0.50
CFM WATTS CFM WATTS CFM WATTS CFM WATTS
036
HI - - - - 1699 825 1650 785
MED 1684 800 1631 780 1582 750 1524 720
LOW 1487 710 1464 690 1421 670 1367 650
048
HI 1996 960 1933 936 1868 910 1795 880
MED 1804 838 1765 810 1714 785 1650 765
LOW 1681 760 1640 738 1604 715 1541 695
060
HI 2400 1155 2338 1125 2274 1095 2167 1045
MED 2290 1105 2214 1065 2145 1030 2071 990
LOW 2150 1020 2100 990 2029 950 1965 910
MODEL
DEE/DEG
MOTOR
SPEED
AVAILABLE EXTERNAL STATIC PRESSURE - IWG
1
0.6 0.70 0.80 0.90 1.00
CFM WATTS CFM WATTS CFM WATTS CFM WATTS CFM WATTS
036
HI 1570 755 1430 725 1360 700 1280 680 1180 655
MED 1410 690 1324 650 1260 630 1185 610 1100 590
LOW 1315 620 1246 605 1185 590 1110 570 1020 545
048
HI 1722 845 1635 820 1544 790 1419 765 1300 740
MED 1589 735 1508 705 1407 675 1306 645 1195 625
LOW 1490 670 1416 645 1337 620 1230 595 1120 575
060
HI 2096 1010 1990 980 1887 945 1771 905 1629 855
MED 1990 950 1911 920 1828 885 1724 835 1604 798
LOW 1905 880 1816 838 1724 800 1644 770 1531 710
1.
Side Duct application (230/460/575 Volts)
2.
Includes allowances for a wet evaporator coil, 1” filters, and the heat exchangers. Refer to Table 12 for resistance val-
ues on applications other than gas / electric units with side duct airflows.
TABLE 12: STATIC RESISTANCES
DESCRIPTION
RESISTANCE, IWG
CFM
1000 1200 1400 1600 1800 2000 2200 2400 2600 2800 3000
ECONOMIZER
1 2
0.07 0.08 0.09 0.11 0.13 0.15 0.17 0.20 0.23 0.26 0.30
ELECTRIC HEATERS
1
5 - 15 kW 0.04 0.05 0.06 0.07 0.08 0.10 0.12 0.14 0.16 0.19 0.22
20 - 30 kW 0.06 0.07 0.08 0.09 0.11 0.13 0.15 0.17 0.20 0.23 0.26
BOTTOM DUCT CONNECTIONS
1
0.06 0.07 0.08 0.09 0.10 0.11 0.12 0.14 0.16 0.19 0.22
COOLING ONLY
3
0.08 0.10 0.12 0.14 0.16 0.18 0.20 0.23 0.26 0.29 0.32
1.
Deduct these resistance values from the available external static pressure shown on Tables 8, 9, 10, and 11.
2.
The pressure through the economizer is greater for 100% outdoor air than for 100% return air. If the resistance of the return air
duct system is less than 0.25 IWG, the unit will deliver less CFM during full economizer operation.
3.
Add these resistance values to the available static resistance in the respective Blower Performance Table (see Tables 8, 9, 10,
and 11).
