York SUNLINE PLUS D1EE036 User Manual

036-21411-002-A-0204
6 Unitary Products Group
Not ARI required
TABLE 1: CAPACITY RATINGS - COOLING / ELECTRIC HEATING
MODEL
ARI RATINGS
1
NOMINAL ELECTRIC HEAT CAPACITY
2
(kW)
COOLING CAPACITY 80 / 67-95°F SOUND
RATING
3
(dBels)
MBH
SEER
4
EER
5
240V 480V 600V
DEE036 42.5 11.5
10.10 86.0
5, 7, 10, 15 &
20
7, 10, 15 & 20 10, 15, & 20
DEE048 49.5 11.0
10.0 86.0
5, 7, 10, 15 &
20
7, 10, 15 & 20 10, 15, & 20
DEE060 58.5 11.0
10.05 86.0
5, 7, 10, 15,
20, & 30
7, 10, 15, 10,
& 30
10, 15, 20 &
30
1.
Certified in accordance with the Unitary Small Equipment certification program, which is based on ARI Standard 210/240.
2.
Heaters are available as accessories - all with single point power supply
3.
Rated in accordance with ARI Standard 270.
4.
SEER =Seasonal Energy Efficiency Ratio - the total cooling output in BTU’s during a normal annual usage period for cooling
divided by the total electric power input in watt-hours during the same period.
5.
EER = Energy Efficiency Ratio - the cooling capacity in BTU’s per hour (BTUH) divided by the power input in watts at any given
set of rating conditions, expressed in BTUH per watt (BTUH/watt).
TABLE 2: CAPACITY RATINGS - COOLING / GAS HEATING
MODEL
ARI RATINGS
1
GAS HEAT CAPACITY
COOLING CAPACITY 80 /
67-95°F
SOUND
RATING
2
(dBels)
INPUT
(MBH)
OUTPUT
(MBH)
AFUE
3
(%) S.S.E.
4
(%)
TEMP.
RISE
(°F)
GASE LINE SIZE
(in. O.D.)
MBH
SEER
5
EER
6
DEG036N040 42.5 11.5 10.1 86 50 40 80.9 81.6 15-45 1/2
DEG036N079 42.5 11.5
10.1 86 100 79 80.5 80.8 40-70 1/2
DEG048N060 49.5 11.0
10.0 86 75 59 80.9 81.6 25-55 1/2
DEG048N099 49.5 11.0
10.0 86 125 99 80.3 80.6 45-75 1/2
DEG060N079 58.5 11.0
10.05 86 100 79 80.5 80.8 25-55 1/2
DEG060N099 58.5 11.0
10.05 86 125 99 80.3 80.6 35-65 1/2
1.
Ratings are in accordance with ARI Standard 210.
2.
Sound ratings are in accordance with ARI Standard 270.
3.
AFUE = Annual Fuel Utilization Efficiency - determined in accordance with DOE test procedure.
4.
S.S.E. = Steady State Efficiency (Percent Output).
5.
SEER =Seasonal Energy Efficiency Ratio - the total cooling output in BTU’s during a normal annual usage period for cooling
divided by the total electric power input in watt-hours during the same period.
6.
EER = Energy Efficiency Ratio - the cooling capacity in BTU’s per hour (BTUH) divided by the power input in watts at any given
set of rating conditions, expressed in BTUH per watt (BTUH/watt).
TABLE 3: SOUND POWER RATINGS
1
UNIT
SIZE
CFM
ESP BLOWER
SOUND POWER (dB 10
-12
WATTS)
OCTAVE BAND CENTERLINE FREQUENCY (Hz)
SWL
dB(A)
dBA
@ 10Ft
2
IWG SPEED kW 63 125 250 500 1000 2000 4000 8000
036 1200 0.60 LOW 0.60 84 84 74 67 69 62 57 52 74 41
048 1600 0.55 HIGH 0.80 85 85 75 68 70 63 58 53 75 42
060 2000 0.45 HIGH 1.00 86 86 76 69 71 64 59 54 76 43
1.
These values have been accessed using a model of sound propagation from a point source into the hemispheric free field. The
dBA values provided are to be used fro reference only. Calculation of dBA values cover matters of system design and the fan
manufacture has no way of knowing the details of each system. This constitutes an exception to any specification or guarantee
requiring a dBA value or sound data in any other form than sound power level ratings.
2.
At a distance of 10 feet from the blower.
Not ARI required
