York YCAE065 - Electrical Data; Electrical Diagram

ELECTRICAL DATA
Model
YCAE065X
YCAE100X
YCAE130X
Power Supply
380V 3N~ 50Hz
380V 3N~ 50Hz
380V 3N~ 50Hz
Voltage Range
342V~418V
342V~418V
342V~418V
MCC
52A
85A
112A
Breaker
63A 4P
100A 3P
160A 3P
Power Cable
10 mm
2
25 mm
2
35 mm
2
Notes
1. Above specifications of wirings and circuit breakers are based on 40℃ ambient temperature.
Please refer to local rules for details.
2. If there are any differences in field (any derating conditions), please refer to IEC standards to
select cables.
ELECTRICAL DIAGRAM
All electrical wiring should be carried out in accordance with local regulations. Route properly sized
cables to the cable entries in the bottom of the power panel.
It is the responsibility of the user to install over current protection devices between the supply
conductors and the power supply terminals on the unit.
To ensure that no eddy currents are set up in the power panel, the cables forming each 3 phase
power supply must enter via the same cable entry.
