Notes
1. Placement on a level surface of free of obstructions (including snow, for winter operation) or air
circulation ensures rated performance, reliable operation, and ease of maintenance.
2. Site restrictions may compromise minimum clearances indicated below, resulting in unpredictable
airflow patterns and possible diminished performance.
3. YORK’s unit controls will optimize operation without nuisance high-pressure safety cutouts;
however, the system designer must consider potential performance degradation.
CLEARANCES
YCAE065X
YCAE100/130X
Recommended minimum clearances:
front to wall – 2m; rear to wall – 2m; control panel end to wall – 2m; cooler end to wall – 2m; top – no
obstructions allowed; distance between adjacent units – 300mm or 400mm. No more than one
adjacent wall may be higher than the unit. 1" nominal deflection isolators (not shown) will increase
overall unit height by 150mm.
