SECTION 8 - MICROPANEL
JOHNSON CONTROLS
121
Form 201.47-ICOM1
Issue date: 17/11/2022
8
SYS X PULLDOWN MOTOR CURRENT LIMITING
The pulldown motor current limiting message indicates
the pulldown motor current load limit or pulldown
motor current unloading is in effect based on the
programmed setpoint.
SYS X BAS CURRENT LIMITING
The BAS Current Limiting message indicates the mo-
tor current load limit or motor current unloading is in
effect through the use of the YORKTalk setpoint.
SYS X REMOTE MOTOR CURRENT LIMITING
The Remote Motor Current Limiting message indicates
the motor current load limit or motor current unloading
is in effect through the use of the remote setpoint off-
set. The setpoint may be offset using a remote voltage
or a current signal. The remote current limit must be
activated for this function to operate.
SYS X VSD BASEPLATE TEMP LIMITING
The VSD Baseplate Temp Limiting message indicates
the VSD Baseplate temp is high and load limit or un-
loading is in effect.
SYS X VSD INTERNAL AMBIENT TEMP LIMITING
The VSD Internal Ambient Temp Limiting message
indicates the VSD internal ambient temp is high and
load limit or unloading is in effect.
SYS X SOUND LIMITING
The sound limiting message indicates the sound load
limit is in effect based on the locally programmed
sound limit from the keypad. The sound limit must be
activated for this function to operate.
SYS X BAS SOUND LIMITING
The BAS sound limiting message indicates the sound
load limit is in effect based on the ISN transmitted
sound limit setpoint. The sound limit must be activated
for this function to operate.
SYS X REMOTE SOUND LIMITING
The Remote sound limiting message indicates the
sound load limit is in effect based on the Remote con-
trolled sound limit setpoint. The setpoint may be offset
using a remote voltage or current signal. The sound
limit option must be activated for this function to
operate.
