Table 37 - Outside air temperature sensor input voltage, measured signal to shield at the sensor
Temperature ºF
(°c)
Voltage
Temperature ºF
(°c)
Voltage
Temperature ºF
(°c)
Voltage
0.24 (-17.6) 0.68 49.8 (9.9) 2.00 93.3 (34.1) 3.31
1.79 (-16.8) 0.71 50.7 (10.4) 2.03 94.4 (34.7) 3.34
3.30 (-15.9) 0.74 51.6 (10.9) 2.06 95.6 (35.3) 3.37
4.76 (-15.1) 0.77 52.5 (11.4) 2.09 96.8 (36) 3.40
6.19 (-14.3) 0.80 53.4 (11.9) 2.11 98.0 (36.7) 3.43
7.58 (-13.6) 0.83 54.3 (12.4) 2.14 99.2 (37.3) 3.46
8.94 (-12.8) 0.85 55.3 (12.9) 2.17 100.4 (38) 3.49
10.3 (-12.1) 0.88 56.2 (13.4) 2.20 101.6 (38.7) 3.52
11.6 (-11.3) 0.91 57.1 (13.9) 2.23 102.9 (39.4) 3.55
12.8 (-10.7) 0.94 58.0 (14.4) 2.26 104.2 (40.1) 3.57
14.1 (-9.9) 0.97 58.9 (14.9) 2.29 105.5 (40.8) 3.60
15.3 (-9.3) 1.00 59.8 (15.4) 2.32 106.8 (41.6) 3.63
16.5 (-8.6) 1.03 60.7 (15.9) 2.35 108.1 (42.3) 3.66
17.7 (-7.9) 1.06 61.6 (16.4) 2.38 109.5 (43.1) 3.69
18.9 (-7.3) 1.09 62.6 (17) 2.41 110.9 (43.8) 3.72
20.0 (-6.7) 1.12 63.5 (17.5) 2.44 112.3 (44.6) 3.75
21.2 (-6) 1.15 64.4 (18) 2.47 113.8 (45.4) 3.78
22.3 (-5.4) 1.18 65.3 (18.5) 2.50 115.2 (46.2) 3.81
23.4 (-4.8) 1.21 66.3 (19.1) 2.52 116.7 (47.1) 3.84
24.4 (-4.2) 1.24 67.2 (19.5) 2.55 118.3 (47.9) 3.87
25.5 (-3.6) 1.26 68.1 (20.1) 2.58 119.9 (48.8) 3.90
26.6 (-3) 1.26 69.1 (20.6) 2.61 121.5 (49.7) 3.93
27.6 (-2.4) 1.32 70.0 (21.1) 2.64 123.2 (50.7) 3.96
28.7 (-1.8) 1.35 70.9 (21.6) 2.67 124.9 (51.6) 3.98
29.7 (-1.3) 1.38 71.9 (22.2) 2.70 126.6 (52.6) 4.01
30.7 (-0.7) 1.41 72.8 (22.7) 2.73 128.4 (53.6) 4.04
31.7 (-0.2) 1.44 73.8 (23.2) 2.76 130.3 (54.6) 4.07
32.7 (0.4) 1.47 74.8 (23.8) 2.76
33.7 (0.9) 1.50 75.8 (24.3) 2.82
34.7 (1.5) 1.53 76.7 (24.8) 2.85
35.7 (2.1) 1.56 77.7 (25.4) 2.88
36.7 (2.6) 1.59 78.7 (25.9) 2.91
37.6 (3.1) 1.62 79.7 (26.5) 2.93
38.6 (3.7) 1.65 80.7 (27.1) 2.96
39.6 (4.2) 1.67 81.7 (27.6) 2.99
40.5 (4.7) 1.70 82.7 (28.2) 3.02
41.4 (5.2) 1.73 83.6 (28.7) 3.05
42.4 (5.8) 1.76 84.6 (29.2) 3.08
43.3 (6.3) 1.79 85.7 (29.8) 3.11
44.3 (6.8) 1.82 86.7 (30.4) 3.13
45.2 (7.3) 1.85 87.8 (31) 3.16
46.1 (7.8) 1.88 88.9 (31.6) 3.19
47.0 (8.3) 1.91 90.1 (32.3) 3.22
48.0 (8.9) 1.94 91.1 (32.8) 3.25
48.9 (9.4) 1.97 92.2 (33.4) 3.28
