York YVAA - Table 9 - Optional Three-Pass Inlet;Outlet Connections

SECTION 5 - TECHNICAL DATA
JOHNSON CONTROLS
75
Form 201.47-ICOM1
Issue date: 17/11/2022
5
All dimensions - in. (mm)
YVAA
Model
A B C1 C2 D D2
E-nozzle
size
Figure
Water
volume gal
(l)
Minimum
chilled water
ow rate
GPM (l/s)
Maximum
chilled water
ow rate
GPM (l/s)
0161/0571
1034.4
(40.72)
345.8 (13.61)
1077.3
(42.41)
1117.6 (44.00)
353.1
(13.90)
678.1 (26.70) 4 A 31 (116) 130 (8.2) 580 (37)
0201/0701
1034.4
(40.72)
345.8 (13.61)
1077.3
(42.41)
1117.6 (44.00)
353.1
(13.90)
678.1 (26.70) 4 A 31 (120) 130 (8.2) 580 (37)
0166/0586
1034.4
(40.72)
1461.8
(57.55)
1077.3
(42.41)
1117.6 (44.00)
353.1
(13.90)
678.1 (26.70) 4 A 31 (120) 130 (8.2) 580 (37)
0211/0741
1034.4
(40.72)
1461.8
(57.55)
1077.3
(42.41)
1117.6 (44.00)
353.1
(13.90)
678.1 (26.70) 4 A 31 (120) 130 (8.2) 580 (37)
0191/0671
1034.4
(40.72)
1461.8
(57.55)
1077.3
(42.41)
1117.6 (44.00)
353.1
(13.90)
678.1 (26.70) 4 A 31 (120) 130 (8.2) 580 (37)
0169/0599
1034.4
(40.72)
2579.8
(101.57)
1077.3
(42.41)
1117.6 (44.00)
353.1
(13.90)
678.1 (26.70) 4 A 31 (120) 130 (8.2) 580 (37)
0214/0754
1034.4
(40.72)
2579.8
101.57)
1077.3
(42.41)
1117.6 (44.00)
353.1
(13.90)
678.1 (26.70) 4 A 44 (170) 130 (8.2) 580 (37)
0196/0686
1034.4
(40.72)
2579.8
(101.57)
1077.3
(42.41)
1117.6 (44.00)
353.1
(13.90)
678.1 (26.70) 4 A 31 (120) 130 (8.2) 580 (37)
0176/0616
1603.6
(63.13)
915.0 (36.02)
1073.3
(42.26)
1117.6 (44.00)
366.7
(14.44)
666.1 (26.22) 5 A 44 (170) 130 (8.2) 860 (54)
0224/0782
1603.6
(63.13)
915.0 (36.02)
1073.3
(42.26)
1117.6 (44.00)
366.7
(14.44)
666.1 (26.22) 5 A 44 (170) 130 (8.2) 860 (54)
0254/0894
1603.6
(63.13)
915.0 (36.02)
1073.3
(42.26)
1117.6 (44.00)
366.7
(14.44)
666.1 (26.22) 5 A 52 (200) 130 (8.2) 860 (54)
Note: The minimum and maximum ow rates listed here only represent the span of ows for a group of available evaporator options. Actual
chiller ow rates vary based on specic evaporator congurations. The application datasheet or nameplate must be referenced for specic ow
limits for every chiller.
Note: Minimum Chilled Water Flow Rate is for full load selections; Variable Primary Flow ratings as low as 50% of the minimum are
permitted. Glycol limits are higher. Contact your Johnson Controls Sales O󰀩ce for ratings and further information.
Table 9 - Optional three-pass inlet/outlet connections
Figure 26 - Optional three-pass inlet/outlet connections
