SECTION 8 - MICROPANEL
JOHNSON CONTROLS
123
Form 201.47-ICOM1
Issue date: 17/11/2022
8
The types of remote control are listed as follows:
• NONE - No remote control is actively controlling
the chiller; however, remote monitoring by a re-
mote device may still be active.
• RCC - A Remote Control Center is providing re-
mote control. The chiller is in remote mode.
• BAS - SC-EQ using Remote BAS connection.
The chiller in remote mode.
• CURR - Remote Current Limiting is enabled.
• TEMP - Remote Temperature Reset is enabled.
• SOUND - Remote Sound Limiting is enabled.
The next key press displays the sound limit values as set
under the PROGRAM key by the Local, BAS, and the
Remote Sound Limit Inputs. Any sound limits that are
inactive will display XXX instead of a numeric value.
UNIT SOUND LIMIT LOCAL = XXX %
BAS = XXX REMOTE = XXX %
