JOHNSON CONTROLS

136

SECTION 8 - MICROPANEL

Form 201.47-ICOM1

Issue date: 17/11/2022

Sound limit setpoint

PROGRAM

SOUND LIMIT SETPOINT = XXX %

This indicates the sound limit setpoint programmed at

the time of the fault, if the sound limit option is activat-

ed at the factory. If the option is not factory activated,

the display will not appear.

Eductor differential temperature

PROGRAM ◄DEF XXXXX LO XXXXX HI XXXXX

EDUCTOR DIFFERENTIAL = XXX °F

This message indicates the programmed eductor dif-

ferential temperature at the time of the fault.

Eductor safety time

PROGRAM ◄DEF XXXXX LO XXXXX HI XXXXX

EDUCTOR SAFETY TIME = XXX MIN

This message indicates the eductor safety time pro-

grammed at the time of the fault.

Motor temperature unload

PROGRAM ◄DEF XXXXX LO XXXXX HI XXXXX

MOTOR TEMPERATURE UNLOAD = XXX °F

This message indicates the motor temperature pro-

grammed at the time of the fault.
