The following four setup OPTION displays are pro-
grammable number pad keys according to the options
installed on the chiller. The following four option are
only used when round tube is selected:
The following setup Option display Voltage Code is
used with compressor type to calculate KW interpola-
tion:
• 380
• 400
• 460
The following three setup OPTION displays are select-

(ARROW) keys.
SETUP MODE REMOTE EVAP CONTROL
◄ ► XXXXXXXXXXXXXXXXXXXXXXXXXXXX
SETUP MODE CONDENSER TYPE
◄ ► XXXXXXXXXXXXXXXXXXXXXXXXXXXX
SETUP MODE ◄DEF XXXXX LO XXXXX HI XXXXX
SYS 1 EVAP LEVEL SETP = XX.X
SETUP MODE ◄DEF XXXXX LO XXXXX HI XXXXX
SYS 2 EVAP LEVEL SETP = XX.X
SETUP MODE ◄DEF XXXXX LO XXXXX HI XXXXX
EVAP VLV STARTUP POS = XX %
SETUP MODE ◄DEF XXXXX LO XXXXX HI XXXXX
EVAP VLV START DELAY = XX %
SETUP MODE VOLTAGE CODE
◄ ► XXX V
SETUP MODE QUICK START UNIT OPERATION
◄ ► XXXXXXXXXXXXXXXXXXXXXXXXXXXX
SETUP MODE ◄DEF XXXXX LO XXXXX HI XXXXX
DISCHARGE PRESSURE CUTOUT = XXX PSIG
SETUP MODE UNIT SOFT SHUTDOWN OPERATION
◄ ► XXXXXXXXXXXXXXXXXXXXXXXXXXXX
SETUP MODE UPDATE SOFTWARE
◄ ► XXXXXXXXXXXXXXXXXXXXXXXXXXXX
SETUP MODE DATA LOGGING MODE
◄ ► XXXXXXXXXXXXXXXXXXXXXXXXXXXX
SETUP MODE ◄DEF XXXXX LO XXXXX HI XXXXX
DATA LOGGING TIME = XX SEC
SETUP MODE ◄DEF XXXXX LO XXXXX HI XXXXX
ANTI RECYCLE TIMER = XXX SECS
The following setup Option display is used to select
and verify refrigerant type:
• R-134a
• R-513A
The following setup OPTION display message appears
when refrigerant selected is R-513A
The following setup Option display is used to select
and verify Chilled Liquid cooling medium:
• WATER
• GLYCOL
The following two setup OPTION display messages
appears when the GTS75 compressor is selected.
SETUP MODE ◄DEF XXXXX LO XXXXX HI XXXXX
ECONOMIZER TRANSITION = XX.X %
SETUP MODE SKIP FREQ Y
◄ ► ZZZ
SETUP MODE ◄DEF XXX LO XXX HI XXX
SKIP FREQ Y LOW LIMIT XXX HZ
SETUP MODE ◄DEF XXX LO XXX HI XXX
SKIP FREQ Y HIGH LIMIT XXX HZ
SETUP MODE INPUT CURRENT LIMITING
◄ ► XXXXXXXXXXXXXXXXXXXXXXXXXXXX
SETUP MODE ◄DEF XXXXX LO XXXXX HI XXXXX
INPUT CURRENT RANGE = XXXX AMPS
SETUP MODE REFRIGERANT TYPE
◄ ► XXXXXXXXXXXXXXXXXXXXXXXXXXXX
SETUP MODE ◄DEF XXXXX LO XXXXX HI XXXXX
DISCH SHEAT SAFETY IGNORE = XXX HZ
SETUP MODE CHILLED LIQUID COOLING MODE
◄ ► XXXXXXXXXXXXXXXXXXXX
SETUP MODE ◄DEF XXXXX LO XXXXX HI XXXXX
SUCT PRESS SENS FAIL BYPASS = XXXX SEC
SETUP MODE ◄DEF XXXXX LO XXXXX HI XXXXX
HIGH AMBIENT RESTART FREQ = XXX HZ
SETUP MODE ◄DEF XXXXX LO XXXXX HI XXXXX
DSCH PRESS RATE THRESHOLD = XX PSI/SEC
SETUP MODE HARMONIC FILTER
◄ ► XXXXXXXXXXXXXXXXXXXXXXXXXXXX
SETUP MODE EVAP ANTI-FREEZE PUMP
◄ ► XXXXXXXXXXXXXXXXXXXXXXXXXXXX
