Yueming MF20 - 1.1 Equipment Composition; 1.1.1 Overall Components

2
1.1 Equipment Composition
Due to different machine models and product update, some models may have different
appearances and details. The actual product shall prevail. Below is the equipment composition of
MF20.
1.1.1 Overall Components
 The front view of the machine is as shown in Fig. 1-2:
Fig. 1-2 FRONT VIEW
① Optical scanner galvanometer
② Optical scanner
field lens
③ Elevating
handwheel
④ XY adjustment platform
⑤ Operation panel
⑥ Keyboard drawer
⑦ Host computer
(internal)
⑧ Fiber laser (internal)
⑨ Fiber output head
⑩ Monitor
⑪ Cooling fan
⑫ Electrical box (internal)
○
2
○
1
○
9
○
3
○
4
○
10
○
5
○
7
○
8
○
11
○
12
○
6
