Fig. 1-13 Machine Nameplate
The machine parameters on the nameplate are as follows:
 Model: The machine model; see Section 1.1 for details (Fig. 1-1);
 Laser Type: Laser type of the machine, mainly fiber laser;
 Laser Power: Rated power of the laser;
 Operating Area: Processing range of the equipment;
 Power Supply: The total input power of the equipment, typically AC 220V; export
models vary by country;
 Total Power: The rated power of the equipment while operating;
 Manufacturing No.: a unique number of each machine;
 Date of Manufacture: The production date of the machine;
1.3 Product Configuration
Master
Unit
No.
Item
Configuration
Specification
Qty.
Manufacturer
Matching
Item
Remark
1
Laser
●
20W
1
Quantel
2
Galvanometer
●
Raylase
1
Imported
1
3
Field lens
●
SL-1064-112-163G
1
Wavelength
Marking format: 110mm
× 110mm, f = 163mm
4
○
SL-1064-140-210
1
Wavelength
Marking format: 140mm
× 140mm, f = 210mm
5
○
SL-1064-70-100
1
Wavelength
Marking format: 70mm ×
70mm, f = 100mm
6
Working
platform
○
X/Y moving
platform
1
Han's
Yueming
Moving distance is about
50mm
7
○
Assembly line
workbench
1
Han's
Yueming
This workbench is made
to order
8
○
Rotating claw plate
1
Han's
Yueming
9
○
Rotating disk
workbench
1
Han's
Yueming
Disc diameter 300mm
10
Lifting frame
○
1
Han's
Yueming
Lifting range is about
600mm
