Appendix
Appendix 1 Electrical Control System Block Diagram of Main
Power
5.1.1
Scanning
galvanometer
Control card &
control loop
AC220V 50HZ
Main power
switch
Switching
power supply
G1: 24V; 5V
Computer
Switching
power supply
G2: ±15V
Intermediate
relay
KA2
Intermediate
relay
KA3
Monitor
Intermediate
relay
KA1
Fiber laser
Switching
power supply
G3: +24V
