AFCZP0BC – COMBIACX & ACEX - User Manual Page - 63/81
Smart driver KO - MDI
CAN 68
Smart driver is open, not able to
provide EB positive
valve, pump, traction stopped,
Lc opened
start-up Key re-cycle
Key-off shorted - MDI CAN
76
Key-off signal is low at Key-on
valve, pump, traction stopped,
Lc opened
start-up Key re-cycle
Evp driv. short - MDI CAN
50
Evp driver is failed shorted (always
ON) mismatch between the valve
set-point and its feedback
valve, pump, traction stopped,
Lc opened, Eb applied
start-up, stby valve or pump or
traction request
Pump Vmn Low - MDI
CAN 28
Pump motor output is too low, with
respect to pwm applied
valve, pump, traction stopped,
Lc opened, Eb applied
start-up, stby,
during pump
function
valve or pump or
traction request
Pump Vmn High - MDI
CAN 29
Pump motor output is too high,
with respect to pwm applied
valve, pump, traction stopped,
Lc opened, Eb applied
during pump
function
valve or pump or
traction request
Wrong Zero - MDI CAN
code alarm 53
The outputs of the amplifiers (used
to measure the motor voltage) are
cheked this alarm occurs when
voltage signals >3V or <2V at the
init
valve, pump, traction stopped,
Lc opened, Eb applied
init valve or pump or
traction request
Evp coil
open - MDI CAN 50
The Evp1 coil is not connected
between PAUX and EVP output,
and the parameter EVP TYPE in
the set-option menu is set Analog
or Digital
valve, pump, traction stopped,
Lc opened, Eb applied
start-up, stby,
traction
valve or pump or
traction request
Aux Batt. Short - MDI CAN
code alarm 74
When the positive of the AUX
OUTPUT is driven by the tiller, the
positive is high and the tiller is
released.
valve, pump, traction stopped,
Lc opened, Eb applied
start-up, stby
Pev not OK - MDI CAN
code alarm 98
The PEV connector (B2) is not
connected to the battery or the
voltage is different.
valve stopped, (eventually)
pump stopped, (eventually)
traction stopped, (eventually)
Lc opened and MC applied
continuous
Controller Mism - MDI
CAN 12
The software is not compatible with
the controller.
valve, pump, traction stopped,
Lc opened, Eb applied
start-up key-recycle
Init vmn low - MDI CAN 72
Motor output voltage lower than
expected, before driving the bridge.
valve, pump, traction stopped,
Lc opened, Eb applied
start-up key-recycle
Init vmn high -
MDI CAN 31
Motor output voltage higher than
expected, before driving the bridge.
valve, pump, traction stopped,
Lc opened, Eb applied
start-up key-recycle
Pump vmn not ok -
MDI CAN 32
Pump motor output voltage is
different than expected
valve, pump, traction stopped,
Lc opened, Eb applied
start-up key-recycle
