Zapi ADPZP0CC - Parameter Programming Flowchart

ADPZP0CC - MHYRIO FLASH CONTROLLER - User Manual Page - 23/36
Flow chart showing how to make changes to Option Menu.
1) Opening Zapi Menu.
MHYRIO F ZAPI V0.0
48V 0A 00000
2) Press ROLL UP & SET UP buttons together to
enter the SET MENU.
% ' %
' ' '
3) The Display will show: SET MODEL.
CONFIG MENU
SET MODEL
4) Press ROLL UP or ROLL DOWN buttons until
SET OPTIONS Menu appears.
% ' '
' ' '
5) SET OPTIONS appears on the display.
CONFIG MENU
SET OPTIONS
6) Press ENTER to go into the SET OPTIONS
Menu.
' % '
' ' '
7) The display will shows the first option.
EV2 TYPE
OPTION1
8) Press ROLL UP or ROLL DOWN buttons until
desired option appears.
% ' '
% ' '
9) Desired option appears.
EV1 TYPE
OPTION1
10) Press SET UP or SET DOWN buttons in order
to modify the value for selected option.
' ' %
' ' %
11) New value for selected option appears.
EV1 TYPE
OPTION2
12) Press OUT to exit the Menu.
' ' '
' % '
13) Confirmation request appears.
ARE YOU SURE?
YES=ENTER NO=OUT
14) Press ENTER to accept the changes, or press
OUT if you do not accept the changes.
' % '
' ' '
' ' '
' % '
15) SET OPTIONS Menu appears.
CONFIG MENU
SET OPTIONS
16) Press OUT again. Display now shows the
Opening Zapi Menu.
' ' '
' % '
