Page 27
5.1.4 Adjustments chart
PARAMETER
PROGRAMMED LEVEL
UNIT 0 1 2 3 4 5 6 7 8 9
ACCELERATION DELAY Sec. 0.41 0.82 1.2 1.6 2 2.4 2.9 3.3 3.7 4.1
INVERS BRAKING % IMax. 19 23 28 32 37 41 46 50 55 59
RELEASE BRAKING % IMax. 15 19 23 27 31 34 38 42 46 50
PEDAL BRAKING % IMax. 25 31 37 43 49 56 62 68 74 80
CUTBACK SP. (1-2-3) % VBatt. 10 22 33 45 53 60 69 78 86 100
COMPENSATION K (I) 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
BRAKING MODUL % IMax. 0 3 5 8 11 14 17 20 22 25
I MAX. (H2 600) Amp. 300 333 367 400 433 467 500 533 567 600
I MAX. (H2 500) Amp. 250 278 306 333 361 388 416 444 472 500
I MAX. (H2 400) Amp. 200 222 244 266 289 311 333 355 378 400
MAX. SPEED FORW-BACK % VBatt. 20 29 38 47 56 64 73 82 91 100
CREEP SPEED % VBatt. 0 1.9 3.9 5.9 7.8 9.8 11.7 13.7 16.6 17.6
WEAK DROPOUT % IMax. 10 20 30 40 50 60 70 80 90 100
CURVE BRAKING % IMax. 15 19 23 27 31 34 38 42 46 50
CURVE TIME sec. 0 0.2 0.3 0.4 0.6 0.8 1 1.2 1.6 2
AUXILIARY TIME sec. 0.1 0.5 2 4 7 9 12 14 17 20
BACKING TIME sec. 0.05 0.2 0.35 0.5 0.75 1 1.5 2 2.5 cont.
BACKING SPEED % VBatt 2 4 8 10 15 20 25 30 40 50
Variant for braking soft
PARAMETER
PROGRAMMED LEVEL
UNIT 0 1 2 3 4 5 6 7 8 9
RELEASE BRAKING % IMax. 7 11 15 19 23 26 30 34 38 42
INVERS BRAKING % IMax. 14 17 21 24 28 31 35 37 41 37
PEDAL BRAKING % IMax. 19 23 28 32 37 42 46 51 55 60
BRAKING MODUL % IMax. 0 2 4 6 8 10 13 15 16 19
CURVE BRAKING % IMax. 11 14 17 20 23 25 28 31 34 37
H2B regenerative traction
