Page 54
6.1.4 ADJUSTMENT CHART
PARAMETER
PROGRAMMED LEVEL
UNIT 0 1 2 3 4 5 6 7 8 9
ACCELERATION DELAY* Sec. 0.15 0.24 0.39 0.50 0.63 0.74 0.86 0.97 1.09 1.22
EV. ACCELER DELAY Sec. 0.39 0.63 0.71 0.81 0.97 1.05 1.27 1.36 1.46 1.54
DECELER DELAY Sec. 0.06 0.13 0.19 0.25 0.31 0.38 0.44 0.50 0.56 0.62
EV. DECELER DELAY Sec. 0.30 0.60 0.70 0.78 0.95 1.04 1.26 1.36 1.43 1.53
I MAX. (H2 600) Amp. 300 333 367 400 433 467 500 533 567 600
I MAX. (H2 500) Amp. 250 278 306 333 361 388 416 444 472 500
I MAX. (H2 400) Amp. 200 222 244 266 289 311 333 355 378 400
SPEED COARSE (ALL) % VBatt. 0 11 22 33 44 55 66 77 88 100
SPEED FINE (ALL) % VBatt. 0 1.2 2.4 3.6 4.8 6.05 7.3 8.5 9.7 10.9
COMPENSAZIONE (ALL) K (I) 10 20 30 40 50 60 70 80 90 100
CREEP SPEED %VBatt. 0 1.9 3.9 5.9 7.8 9.8 11.7 13.7 16.6 17.6
WEAK DROPOUT %IMax. 10 20 30 40 50 60 70 80 90 100
HYDRO TIME sec. 0 0.5 2 4 7 9 12 14 17 20
MIN VALVE VOLT %VBatt. 7.4 11.3 15.2 19.2 23.1 27.0 31 35 39 43
MAX VALVE VOLT %VBatt. 56 60 64.5 70 74 78.5 83.5 88 92.5 97.5
H2B standard lifting
