59
option, pressing【ENTER】to enter into the measuring interface as
shown in figure3-43. The measuring interface is composed by result
display area and parameter area. The top of screen is the result display
area with legend to show measuring result of every measuring point
and different legends represent different potentials.
Users can set under “Icon” menu, operation please refer to in 3.5.2.3.
The lower part is parameter area, displaying current ordinate, object
No., current tested potential and test direction.
Figure 3-43 Rust test interface
3.5.2.6 Data display
Pressing 【a】or【b】 in main menu to shift cursor to “Data Display”
option, pressing【ENTER】to enter into data display interface. The left
side of screen will display list of tested objects, right side with
statistical results of corresponding test data as shown in figure3-44.
Object No. displays in inverse order, that is, the last tested object will
display first.
Figure 3-44 Data display
