Operations
SEH PS105-Z External Print Server
26
P1004197-001 Addendum to the SEH PS105-Z & PS102-Z User Guide 09/03/2008
for Zebra Printers
SEH PS105-Z External Print Server
Figure 4 shows key components of the external print server (PS105-Z). You should familiarize
yourself with the various LED’s and connectors for the print server before you begin.
Figure 4 • SEH PS105-Z
1
Link LED
2
Activity LED
3
Status LED
4
RJ45 connector
5
Parallel port (Centronics) connector
