Configuration
Control Panel
38
P1004197-001 Addendum to the SEH PS105-Z & PS102-Z User Guide 09/03/2008
for Zebra Printers
Parameters for V53.16.x Firmware
The S4M printer uses V53.16.x firmware.
Table 5 shows the network parameters that may be viewed or modified through the S4M
control panel. To view wireless and network parameters that are not available as selections
through the control panel, print a network configuration label.
Note • Refer to the S4M User Guide for specific instructions on how to use the control panel.
Table 5 • Wireless Parameters for V53.16.x Firmware
(S4M Printer)
Parameter Explanation
Password Level 3 Parameters
ACTIVE PRINTSR
1
View the Active Print Server
This menu item displays which print server is being used. This tells which
device’s settings such as IP protocol and IP address are being displayed
under those menu items.
Selections:
• WIRELESS indicates that the wireless device is active.
• EXTERNAL WIRED indicates that the external print server is active.
• NONE indicates that at least one of the network options is installed but
none of them are active. When NONE is shown for this menu item, the
device-specific items such as IP protocol and IP address will not display.
Default Value: NONE
RESET NETWORK
1
Reset the Wired or Wireless Network
Use this parameter to reinitialize the wireless radio card and the print server
(wired or wireless) when the wireless print server is running. This
parameter also causes any wireless radio card in the printer to reassociate to
the wireless network. (Same function as ZPL command ~WR. For more
specific details about SGD commands, see ZPL II
®
Programming Guide
For x.14 Firmware and Above.)
1 Appears after the printer recognizes the existence of a print server (wired or wireless).
