Zebra 110Xi4 User Manual

139
Troubleshooting
Print Quality Problems
3/12/09 Xi4 User Guide P1009874-001
Misregistration/skips
labels
The printer is not calibrated. Recalibrate the printer.
The media sensor is not
positioned correctly.
Perform media sensor position adjustment.
Improper label format. Use correct label format.
Misregistration and
misprint of one to
three labels
The platen roller is dirty. See Clean the Printhead and Platen Roller
on page 118.
The media sensor is not
positioned correctly.
Place the media sensor in the proper position.
Media does not meet
specifications.
Use media that meets specifications.
Vertical drift in
top-of-form position
The printer is out of calibration. Recalibrate the printer.
Vertical drift occurs during
normal printer operation.
Note • A vertical drift of
± 4 to 6 dot rows
(approximately 0.5 mm)
is within normal
tolerances.
Calibrate the printer. See Calibrate Media and
Ribbon Sensor Sensitivity on page 101.
The platen roller is dirty. Clean the platen roller. See Clean the Printhead
and Platen Roller on page 118.
Vertical image or
label drift
The printer is using
non-continuous labels but is
configured in continuous mode.
Configure the printer for non-continuous and run
calibration routine, if necessary.
The media sensor is positioned
incorrectly.
Ensure that the media sensor is properly
positioned to read a single/consistent interlabel
gap.
The media sensor is calibrated
improperly.
See Calibrate Media and Ribbon Sensor
Sensitivity on page 101.
The platen roller is dirty. Clean the platen roller. See Clean the Printhead
and Platen Roller on page 118.
Improper printhead pressure
settings (toggles).
Adjust the printhead pressure to ensure proper
functionality.
Improperly loaded media. Verify that the printer is loaded properly.
Incompatible media. Ensure that the interlabel gaps or notches are 2 to
4 mm and consistently placed. Media must not
exceed minimum specifications for mode of
operation.
Table 13 • Print Quality Problems (Continued)
Problem Possible Cause Recommended Solution

Zebra 110Xi4 Specifications

General

Maximum resolution	203 x 203 DPI
Core diameter	76 mm
Ribbon length	300 m
Media thickness	0.076 - 0.305 mm
Maximum media length	3810 mm
Maximum roll diameter	203 mm
Supported paper width	102 mm
Media thickness (imperial)	0.003 - 0.012 \
Maximum media length (imperial)	150 \
Supported paper width (imperial)	4 \
RS-232 ports	1
Standard interfaces	USB 2.0
Connectivity technology	Wired
Weight (imperial)	50 lbs
Dimensions (WxDxH)	261.9 x 517.5 x 393.7 mm
Flash memory	8 MB
Certification	-BSMI, -cTUVus, -CCC, -CE, -C-Tick, -EN55022 Class B, -EN55024, -EN61000-3-2, 3, -FCC Class B, -GOST-R, -ICES-003 Class B, -IEC 60950-1 / EN60950, -KCC, -NOM, -S Mark, -STB, -UkrSEPRO, -VCCI, -ZIK.
Internal memory	16 MB
Built-in barcodes	Code 39, Code 49, Code 93, MaxiCode, PDF417, Postnet, QR Code, UPC-A, UPC-E
Page description languages	XML, ZPL, ZPL II
Storage temperature (T-T)	-40 - 140 °F
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Power requirements	90 - 264 VAC, 48 - 62 Hz

Weight and Dimensions

Weight	22700 g
