95
Configuration
Standard Control Panel Parameters
3/12/09 Xi4 User Guide P1009874-001
Set Maximum Label Length
This parameter is used during the media portion of the calibration process.
Always set maximum label length to a value that is at least 1.0 in.
(25.4 mm) greater than the actual label length (Figure 15). If the value is set
to a smaller value than the label length, the printer assumes that continuous
media is loaded, and the printer cannot calibrate.
For example, if the label length is 5.0 inches (126 mm) including the
interlabel gap, set the parameter for 6.0 inches (152 mm). If the label length
is 7.5 inches (190 mm), set the parameter for 9.0 inches (229 mm).
Figure 15 • Label Length
Default Value: 39.0 inches (988 mm)
Selections: Values are adjustable in one-inch (25.4 mm) increments
To change the value shown:
1. Press PLUS (+) or MINUS (-) to change the value shown.
Set Supplies Low Warning
When this feature is enabled, the printer provides a warning when the
media or ribbon level is low.
Default: DISABLED
Selections: ENABLED, DISABLED
Table 9 • Printer Parameters (Sheet 5 of 22)
Language/Parameter
Action/Explanation
}
2
1
Label length (including interlabel gap)
2
Interlabel gap
3
Set maximum label length to approximately this value
1
3
To Next Page
