O-4
UMAN-CM2/3
continued next page
Removing and Replacing Cameo 2
Battery Packs
To remove the battery pack from the Cameo 2:
1.Push the battery release button on the bottom of
the printer towards the media compartment.
2.Rotate the belt clip as shown while,
3.Allowing the battery pack to slide out.
Battery Packs are replaced by the following procedure:
1. Rotate the Belt Clip to clear the battery
2.Align the battery pack to the bottom of the printer.
The side of the battery with the contacts will face
into the well for the battery.
3.Slide the pack completely into the printer until it
locks in place. The battery will engage with a
distinct “click”.
4. Rotate the Belt Clip back into position.
REMOVING AND REPLACING CAMEO 2
SERIES BATTERY PACKS (CAMEO 2
SC
SHOWN.)
Belt Clip
Push Release Latch to
remove battery pack.
Battery Pack
