O-5 UMAN-CM2/3
Removing and Replacing Cameo 3 Battery Packs
To remove the battery pack from the Cameo 3:
Slide the Battery Latch button in the direction shown in
the top illustration below, and slide the battery out.
To replace the battery, insert the end with the contacts
into the battery well and slide the battery into the printer
until in clicks into place .
Low Battery Shutdown
As the battery charge level in becomes depleted the
Power LED will flash. At this time the printer should be
shut off and the battery pack recharged or replaced.
Cameos will automatically shut off if the batteries become
severely discharged.
Safety Warnings
Use of a charger not approved by Zebra for use with Cameo
series NiMH batteries could damage the battery pack or the
printer and will void the warranty.
Battery terminals are recessed to prevent short circuiting of the
battery. Allowing these terminals to contact conductive mate-
rial will create a short circuit which could cause burns, other
injuries or start a fire.
Battery Latch
Button
Battery Pack
R
EMOVING AND REPLACING CAMEO 3
BATTERY PACKS
