Zebra S4M

47
Operations
Load Media in Peel-Off Mode
6/15/09 S4M User Guide 13290L-004 Rev. A
4. Feed the media under the dancer assembly (1), through the slot in the transmissive
sensor (2—standard transmissive sensor shown), and under the ribbon sensor (
3).
5. Push down the peel-off mechanism release lever to open the peel assembly.
6. Pull approximately 18 in. (500 mm) of media through the front of the printer.
123
