Configuration
Password Protection of Parameters
6/15/09 S4M User Guide 13290L-004 Rev. A
Note • When you enter a password at an ADVANCED SETUP prompt, the first parameter
that you see is determined in part by whether you pressed the right arrow or the left arrow to
get to the
ADVANCED SETUP prompt:
• If you used the right arrow, the first parameter that you see is based on the password level
that the printer prompted for (see Table 12).
• If you used the left arrow, the first parameter that you see is based on which password you
enter at the prompt, regardless of which password level the printer prompted for
(see Table 13).
Table 12 • Right Arrow Used to Reach
ADVANCED SETUP Prompt
Advanced
Setup Level
Prompted
Password
Level
Entered
First Parameter Seen
1 1, 2, 3, or 4 DARKNESS (top of level 1)
2 2, 3, or 4
MEDIA TYPE (top of level 2)
33 or 4
PRINT OUT (top of level 3)
44
LABEL LEVEL (top of level 4)
Table 13 • Left Arrow Used to Reach
ADVANCED SETUP Prompt
Advanced
Setup Level
Prompted
Password
Level
Entered
First Parameter Seen
11 LABEL TOP (ZPL, EPL, APL-D)
(bottom of level 1)
Y FORMS ADJUST (APL-I)
(bottom of level 1)
1, 2 2
LENGTH
(bottom of level 2)
1, 2, 3 3
LANGUAGE
(bottom of level 3)
1, 2, 3, or 4 4
LANGUAGE
(bottom of level 4;
LANGUAGE parameter appears in
both level 3 and 4)

Zebra S4M Specifications

General

Flash memory	4 MB
Internal memory	8 MB
Dimensions (WxDxH)	272 x 477 x 295 mm
Media types supported	continuous, die-cut, tag, black mark
Media thickness	0.076 - 0.15 mm
RS-232 ports	1
Standard interfaces	USB 2.0
Storage temperature (T-T)	5 - 40 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Weight	12400 g
