Configuration
Control Panel Parameters
78
13290L-004 Rev. A S4M User Guide 6/15/09
MODULE A
(APL-D mode only)
Set Module A Storage Device for APL-D
This parameter allows you to assign an actual 512 KB memory device to a
module letter.
Selections: NONE, RAM 1, RAM 2, FLASH 1, FLASH 2
Default Value: NONE
To modify this parameter:
• Press the up or down arrow to scroll through the selections.
MODULE B
(APL-D mode only)
Set Module B Storage Device for APL-D
This parameter allows you to assign an actual 512 KB memory device to a
module letter.
Selections: NONE, RAM 1, RAM 2, FLASH 1, FLASH 2
Default Value: NONE
To modify this parameter:
• Press the up or down arrow to scroll through the selections.
PARALLEL COMM.
Set Parallel Communications
Select the communications port that matches the one being used by the host
computer.
Selections: UNIDIRECTIONAL, BIDIRECTIONAL
Default Value: UNIDIRECTIONAL
To modify this parameter:
• Press the up or down arrow to scroll through the selections.
PRINT PAGE
(APL-I mode only)
Print Stored APL-I Page
Up to 20 pages can be stored and printed.
Selections: 0 through 19
Default Value: 0
To modify this parameter:
• To increase the value, press the up arrow.
• To decrease the value, press the down arrow.
PRINT FORMAT
(APL-I mode only)
Print Stored APL-I Format
Up to 100 formats can be stored and printed.
Selections: 0 through 99
Default Value: 0
To modify this parameter:
• To increase the value, press the up arrow.
• To decrease the value, press the down arrow.
Table 15 • Printer Parameters, Password Level 3 (Page 2 of 10)
Parameter Explanation
