Configuration
Control Panel Parameters
6/15/09 S4M User Guide 13290L-004 Rev. A
BAUD
Set Baud
The baud setting of the printer must match the baud setting of the host
computer for accurate communications to take place. Select the value that
matches the one being used by the host computer.
Selections (ZPL, APL-I, APL-D): 300, 600, 1200, 2400, 4800, 9600,
14400, 19200, 28800, 38400, 57600, 115200
Selections (EPL): 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200
Default Value: 9600
To modify this parameter:
• Press the up or down arrow to scroll through the selections.
DATA BITS
Set Data Bits
The data bits of the printer must match the data bits of the host computer
for accurate communications to take place. Set the data bits to match the
setting being used by the host computer.
Note • Code Page 850 requires the data bits to be set to 8 bits.
Selections: 7BITS, 8BITS
Default Value: 8BITS
To modify this parameter:
• Press the up or down arrow to scroll through the selections.
STATUS RESPONSE
(APL-I mode only)
Send APL-I Status Response
Determines if a response is sent after inquiry commands.
Selections: ON, OFF
Default Value: ON
To modify this parameter:
• Press the up or down arrow to scroll through the selections.
PARITY
Set Parity
The parity of the printer must match the parity of the host computer for
accurate communications to take place. Select the parity that matches the
one being used by the host computer.
Selections: NONE, ODD, EVEN
Default Value: NONE
To modify this parameter:
• Press the up or down arrow to scroll through the selections.
Table 15 • Printer Parameters, Password Level 3 (Page 3 of 10)
Parameter Explanation

Zebra S4M Specifications

General

Flash memory	4 MB
Internal memory	8 MB
Dimensions (WxDxH)	272 x 477 x 295 mm
Media types supported	continuous, die-cut, tag, black mark
Media thickness	0.076 - 0.15 mm
RS-232 ports	1
Standard interfaces	USB 2.0
Storage temperature (T-T)	5 - 40 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Weight	12400 g
