Zebra S4M User Manual

Configuration
Control Panel Parameters
84
13290L-004 Rev. A S4M User Guide 6/15/09
SENSOR PROFILE
Print Sensor Profile
Use the sensor profile (Figure 19) to troubleshoot registration problems
that may occur if the media sensor detects preprinted areas on the media or
if it experiences difficulty in determining web location. To adjust the
sensitivity of the media and/or ribbon sensors, use Calibrate Media and
Ribbon Sensors on page 85.
Note • The ribbon portion of the label appears only for printers
that have the Thermal Transfer option installed.
Figure 19 • Sensor Profile
To select this parameter:
1. Press ENTER to start this standard calibration procedure and print a
media sensor profile.
Table 15 • Printer Parameters, Password Level 3 (Page 8 of 10)
Parameter Explanation

Zebra S4M Specifications

General

Flash memory	4 MB
Internal memory	8 MB
Dimensions (WxDxH)	272 x 477 x 295 mm
Media types supported	continuous, die-cut, tag, black mark
Media thickness	0.076 - 0.15 mm
RS-232 ports	1
Standard interfaces	USB 2.0
Storage temperature (T-T)	5 - 40 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Weight	12400 g
