Zebra WT6000 User Manual

Data Capture
55
Figure 47 Pick List Mode with Multiple Bar Codes in Aiming Pattern
4. The captured data appears in the text field.
Pairing the RS507/RS6000 Hands-Free Imager
To connect the RS507 or RS6000 imagers to the WT6000, use one of the following methods:
• Near Field Communication (NFC)
• Simple Serial Interface (SSI)
• Bluetooth Human Interface Device (HID) Mode.
Pairing Using Near Field Communication
The WT6000 provides the ability to pair the RS6000 using NFC.
1. Ensure that the RS6000 is in SSI mode. Refer to the RS6000 User Guide for more information.
2. Ensure that NFC is enabled on the WT6000.
3. Align the NFC icon on the RS6000 with the NFC icon on the WT6000.
The Status LED blinks blue indicating that the RS6000 is attempting to establish connection with the WT6000.
When connection is established, the Status LED turns off and the RS6000 emits a single string of low/high
beeps.
A notification appears on the WT6000 screen and the icon appears in the Status bar.
NOTE: RS6000 only.

Zebra WT6000 Specifications

General

Display diagonal	3.2 \
Display brightness	400 cd/m²
Display resolution	800 x 480 pixels
Gorilla Glass version	Gorilla Glass 3
Display number of colors	16.78 million colors
Flash memory	8 GB
Internal memory	2 GB
Internal memory type	-
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Number of cores	4
Processor frequency	1 GHz
Battery capacity	3350 mAh
GPS (satellite)	No
Operating system installed	Android
Product color	Black
International Protection (IP) code	IP65
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
Operating frequency	2412 - 2472, 5180 - 5835 MHz
Security algorithms	EAP-FAST, EAP-TLS, EAP-TTLS, LEAP, MSCHAPv2, WEP, WPA-TKIP, WPA2-AES, WPA2-TKIP
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	34 mm
Width	121 mm
Height	89 mm
Weight	245 g
