Accessories
96
2-Slot WT6000/RS6000 Charging Cradle
The 2-Slot WT6000/RS6000 Charging Cradle:
• provides 5.4 VDC (nominal) power for operating the WT6000 and RS6000.
Figure 80 2-Slot WT6000/RS6000 Charging Cradle
Charging the WT6000
1. If charging a WT6000 with a standard battery, insert either end of the WT6000 into the WT6000 charging slot.
NOTE: Ensure that you follow the guidelines for battery safety described in Battery Safety Guidelines on page 128.
RS6000 Charging LED
RS6000 Charging Slot
Power LED
WT6000 Charging Slot
WT6000 Charging LED
