DALIBOX Interface 64/32
http://www.zennio.com Technical Support: http://support.zennio.com
2.7 SEQUENCES
2.7.1 CONFIGURATION
This feature allows defining up to 16 configurable dimming sequences, which can
perform actions on different groups. Sequences can be executed simultaneously, as
starting a new one does not stop other sequences in execution.
ETS PARAMETERISATION
Once this function has been enabled, the following objects will show in ETS:
“Sequence Control” (one byte): will trigger the sequence whose number is
received through the object, as detailed next:
Table 3. Sequence Control
“Sequence Launcher” (one byte): similar to the scenes object (see section
2.6), but without the “save” functionality:
Table 4. Sequence Launcher
“Stop Sequences” (one bit): interrupts all current sequences when it receives
either a “1” or a “0”.
The “Configuration” tab in ETS contains the following parameters:
Sequence N [enabled/disabled]: enables sequence number N.
A specific tab will be incorporated for each sequence being enabled.
