Figure 28. Configuration
2.7.2 SEQUENCE N
Each sequence can consist of up to five actions executed sequentially. For each of the
actions, it is possible to set the group over which the action will be performed, as well as
the target dimming value, the dimming type (at once or smooth) and the total length of
the action prior to trigger the next one.
ETS PARAMETERISATION
The “Sequence N” tab contains the following parameters:
Figure 29. Sequence N
Sequence Number [1…64]: sets the sequence identifying number whose
reception through the aforementioned communication objects will make the
device trigger the sequence.
Cyclic [enabled/disabled]: sets whether the sequence should start over or not
after the execution of the last action.
