2.4 NO GROUP
2.4.1 ECG N
Ballasts that have been enabled but have no group assigned yet will still provide some
basic configuration options, analogous to those provided by ballasts that do have a group
assigned, although none of the functions that can be configured for groups will be
available for ballasts without a group.
These basic options are:
Name: name of up to twelve characters that will identify the ballast along the
options of the device display, for example during group assignment or for the
manual control function.
Operating time counter: function that informs the KNX bus about the
operation time, i.e., how much time the ballast has remained under a dimming
level greater than 0% since DALIBOX Interface 64/32 took over the control of
the ballast.
ECG Type: sets the ECG type.
ETS PARAMETERISATION
When new ballasts with no group assignment become enabled (see section 2.2), new
sub-tabs (one per ballast) will be incorporated under the “No Group” tab, providing the
following options:
Figure 12. No Group – ECG N
