Name: desired identifier for the ballast (up to twelve characters).
Enable Operating Time Counter Object [enabled/disabled]: enables the
“[ECG N] Operating Time” four-byte object, which shows (in seconds,
although updated every hour) how much time DALIBOX Interface 64/32 has
been regulating the ballast with a dimming level greater than 0%. This object
can be overwritten to change the value, for example in case of a ballast
replacement. It can also be reset by means of the “Installation” menu on the
display, as detailed in section 2.8.
ECG type [Normal ECG / Self-contained Battery Light (Converter) / LED
Module]: in case of selecting “Self-contained Battery Light (Converter)”, the
following parameters are shown:
➢ Value in Emergency Mode [0…100] [%]: sets the brightness level of the
lamp in emergency mode.
➢ Prolong Time on Recovery [0…20] [min]: sets the time to remain in the
extended emergency mode after main voltage recovery.
➢ Function Test Interval [0…255] [days]: sets the periodic time for automatic
execution of the test which checks the proper function of the converter.
➢ Duration Test Interval [0…52] [weeks]: sets the periodic time for automatic
execution of the test which checks converter is working properly in case of
power failure.
➢ Partial Duration Test Interval [0…52] [weeks]: sets the periodic time for
automatic execution of partial duration test. This test checks faster than
duration test that, in case of power failure, the battery life is appropriate.
➢ Partial Duration Test Duration (0 = Disabled) [0…60] [min]: sets the
duration time for automatic execution of the partial duration test.
➢ Test Execution Timeout [0…255] [days]: sets the maximum time after
which the function test or duration test must be executed. If a test has not
ended within this time the result will indicate max delay exceeded.
