Dimming Time [At Once / Dimming Time 1 / Dimming Time 2 / Dimming Time
3 / Time to Next Action]. In case of selecting “Time to Next Action”, the dimming
time –i.e., the total time for a transition from 0% to 100– will match the action
time, which is configured through the next parameter.
Time to Next Action [0…10…255] [s/min]: defines the length of the action,
i.e., the time it will take until the next action begins.
Send Luminosity During Sequence [enabled/disabled]: sets whether the
“[Group X] Dimming Value (Status)” object should be sent during the
sequence.
An example of custom sequence configuration is shown in Figure 30.
Important: in order to avoid action overlapping between groups or within the same
group, please configure the Dimming Time and the Time to Next Action with caution.
