Zennio FLAT - Page 54

Flat & Flat 55
http://www.zennio.com Technical Support: http://support.zennio.com
54
1 Bit
C T - - -
DPT_Step
0/1
[Ix] [Long Press] Stop/Step Up Shutter
Sending of 0 (Stop/Step Up)
1 Bit
C T - - -
DPT_Step
0/1
[Ix] [Long Press] Stop/Step Down Shutter
Sending of 1 (Stop/Step Down)
1 Bit
C T - - -
DPT_Step
0/1
[Ix] [Long Press] Stop/Step Shutter
(Switched)
Switching of 0/1 (Stop/Step Up/Down)
4 Bit
C T - - -
DPT_Control_Dimmin
g
0x0 (Stop)
0x1 (Dec. by 100%)
…
0x7 (Dec. by 1%)
0x8 (Stop)
0x9 (Inc. by 100%)
…
0xF (Inc. by 1%)
[Ix] [Long Press] Brighter
Long Pr. -> Brighter; Release -> Stop
4 Bit
C T - - -
DPT_Control_Dimmin
g
0x0 (Stop)
0x1 (Dec. by 100%)
…
0x7 (Dec. by 1%)
0x8 (Stop)
0x9 (Inc. by 100%)
…
0xF (Inc. by 1%)
[Ix] [Long Press] Darker
Long Pr. -> Darker; Release -> Stop
4 Bit
C T - - -
DPT_Control_Dimmin
g
0x0 (Stop)
0x1 (Dec. by 100%)
…
0x7 (Dec. by 1%)
0x8 (Stop)
0x9 (Inc. by 100%)
…
0xF (Inc. by 1%)
[Ix] [Long Press] Brighter/Darker
Long Pr. -> Brighter/Darker; Release -> Stop
1 Bit
C T - - -
DPT_Switch
0/1
[Ix] [Long Press] Light On
Sending of 1 (On)
1 Bit
C T - - -
DPT_Switch
0/1
[Ix] [Long Press] Light Off
Sending of 0 (Off)
1 Bit
I
C T - W -
DPT_Switch
0/1
[Ix] [Long Press] Light On/Off
Switching 0/1
1 Byte
C T - - -
DPT_SceneControl
0-63; 128-191
[Ix] [Long Press] Run Scene
Sending of 0 - 63
1 Byte
C T - - -
DPT_SceneControl
0-63; 128-191
[Ix] [Long Press] Save Scene
Sending of 128 - 191
1 Bit
O
C T R - -
DPT_Alarm
0/1
[Ix] [Switch/Sensor] Alarm: Breakdown or
Sabotage
1 = Alarm; 0 = No Alarm
2 Bytes
C T - - -
9.xxx
-671088.64 -
670760.96
[Ix] [Long Press] Constant Value (Float)
Float Value
2 Bytes
C T - - -
DPT_Value_2_Ucount
0 - 65535
[Ix] [Long Press] Constant Value (Integer)
0 - 65535
1 Byte
C T - - -
DPT_Scaling
0% - 100%
[Ix] [Long Press] Constant Value
(Percentage)
0% - 100%
1 Byte
C T - - -
DPT_Value_1_Ucount
0 - 255
[Ix] [Long Press] Constant Value (Integer)
0 - 255
210, 216
1 Bit
C T - - -
DPT_Trigger
0/1
[Ix] [Long Press/Release] Stop Shutter
Release -> Stop Shutter
211, 217
1 Byte
I
C - - W -
DPT_Scaling
0% - 100%
[Ix] [Long Press] Dimming Status (Input)
0% - 100%
1 Byte
I
C - - W -
DPT_Scaling
0% - 100%
[Ix] [Long Press] Shutter Status (Input)
0% = Top; 100% = Bottom
