2.2.2 DISABLED
While a button stays disabled, it will not be functional: touching on it will not cause the
execution of actions, nor will make the associated LED light.
ETS PARAMETERISATION
This function has no related parameters.
2.2.3 INDIVIDUAL
Buttons configured to work as individual (separate) controls can be assigned any of the
following control functions:
LED indicator: user presses will not trigger any function although the LED
will turn on or off depending on the values received from the bus.
Switch: whenever the user touches the button, a binary value will be sent to
the KNX bus. This value is configurable and may be 0 or 1, or alternate with
every touch according to the sequence 1 0 1 …
Under a “State-dependent” LED illumination, the LED will remain on/off
according to the current state (on/off) of the object.
Hold & Release: as soon as the user touches the button, a binary value (“0”
or “1”, configurable) will be sent to the KNX bus. And as long as the user
releases the button, another value (“0” or “1”, also configurable) will be sent
through the same object.
The “State-dependent” LED mode is not available for this function.
Two Objects (Short Press / Long Press): specific binary values will be sent
both after a short or a long press (a different object will be used in each
case). Under a “State-dependent” LED illumination, the LED will remain on/off
according to the current state (on/off) of either one object or the other, which
can be configured in parameters. However, if LED Illumination Control (All
Buttons) has been set to “State-dependent (where available)”, only the short
press object will apply.
Scene: after the user touches the button, an order to run a specific scene
(configurable) will be sent to the bus. If enabled in parameters, orders to save
