Pump with Bracket Installation Instructions
4. Insert the U-shaped copper pipe into the top of the discharge line and fasten into place with the supplied wire clamp. Hang the U-shaped
copper over the edge of the evaporation pan. For pan sharing, set up the second discharge line the same way.
5. Attach the overow line to the overow exit on the evaporation pan. Use cable ties to secure the lines together.
6. Plug the evaporation pan into the outlet receptacle on the back of the upper electrical box. For Reveal Merchandiser
®
, the store must
supply power for the evaporation pan.
AFTER SETTING AND SHIMMING THE CASE
7. Apply PVC primer and PVC adhesive to the case drain lateral and attach it to the pipe elbow under the case.
8. Fasten the piping bracket to the front of the foamed oor and run the case drain lateral through it.
Hang discharge
line over edge
Attach overow line
to overow exit
Secure
lines
together
Hang both
discharge lines
over edge
Attach overow line
to overow exit
Secure
lines
together
Attach case drain
lateral to pipe elbow
Fasten piping
bracket
Pan Sharing Shown
