22 • Plumbing
PLUMBING
Pump with Bracket Installation Instructions
9. Place the vinyl tube with PVC elbow over the inlet to the condensate pump. Fasten into place using the supplied hose clamp.
10. Use PVC primer and PVC adhesive to glue the PVC elbow to the case drain lateral. Route the vinyl tube in the correct direction and make
sure it is angled downward for proper ow.
a. 1 to 3-door cases: Route the vinyl tube to the left from the case drain lateral. For 1-door cases, the clear vinyl tubing will need to be
cut to t.
a. 4 to 6-door cases: Route the vinyl tube to the right from the case drain lateral.
PVC elbow must be
angled downward
Attach vinyl tube
to the pump inlet
Hose Clamp
To Next Page
