Plumbing • 23
PLUMBING
Pump with Bracket Installation Instructions
11. On a Highlight Merchandiser
®
, install the pump bracket into the holes in the foamed oor. The condensate pump will hang on the pump
bracket with hooks that are molded into the pump. Crystal Merchandiser
®
and Reveal Merchandiser
®
do not use a pump bracket. Set the
pump on the oor instead.
12. Take the discharge line from under the case and attach it to the pump outlet.
13. Plug the condensate pump into the provided outlet receptacle.
14. After the case is powered, dump water down the case drain to prime the pump. You will see the water level in the clear vinyl tube. This
creates the drain trap for the case.
Set the Condensate Pump into the Pump Bracket
(to the left on 1 to 3-door cases)
Attach discharge line
to the pump outlet
Set the Condensate Pump into the Pump Bracket
(to the right on 4 to 6-door cases)
Attach discharge line
to the pump outlet
Highlight Merchandiser
®
Shown
The vinyl tube and pump now
create the drain trap for the case
