Motherboard Installation
Page 12
TX98-3D
A. AT Power Supply Connector K. Audio CD Connectors
B. ATX Power Supply Connector L. PCI Bus Connector
C. AT Keyboard Connector M. ISA Bus Connectors
D. Serial (COM1 and 2) Headers
E. Parallel (Printer) Port Header O. Front Panel Connector
F. Integrated Functions Connector P. TC-LINK SCSI Header
G. 3.3v DIMM Sockets Q. WAKEUP-LINK Header
H. SIMM RAM Sockets R. TA-LINK Intel LAN Header
I. Floppy Drive Connector S. IDE Connectors
J. Audio Connector T. Pentium Socket 7
